The Core Power VRLA (Valve-Regulated Lead Acid) UPS Battery is a cornerstone in the realm of uninterruptible power supply (UPS) systems, providing a reliable and maintenance-free energy storage solution for various applications where power continuity is critical. Known for its robustness and efficiency, this battery type is especially favored in environments where power disruptions can lead to significant losses, such as data centers, hospitals, and industrial settings.



Design and Technology

Core Power VRLA batteries employ a sealed design, which means they are maintenance-free, as there’s no need to check or replenish liquid levels. This sealing is achieved through an internal pressure relief valve that regulates gas emissions, preventing both over-pressure and the escape of electrolyte. These batteries come in two primary types within the VRLA category: Absorbent Glass Mat (AGM) and Gel. AGM batteries use a fiberglass mat to absorb the electrolyte, while Gel batteries use a gel form of the electrolyte, each offering unique benefits tailored to specific applications.



Performance and Efficiency

One of the key advantages of the Core Power VRLA UPS Battery is its low self-discharge rate, which allows for extended storage periods without significant capacity loss. They are also known for their capability to deliver high currents when needed, which is crucial for UPS applications where the battery must kick in quickly to maintain power to critical systems during an outage. The design life of these batteries varies, typically offering a lifespan of 4 to 10 years, depending on usage patterns and environmental conditions like temperature.



Applications and Benefits

These batteries are integral to UPS systems because they provide instant backup power, ensuring that there’s no gap between power failure and the activation of the backup system. This is vital for protecting sensitive equipment from power surges or outages. The Core Power VRLA batteries are also praised for their ease of installation; they can be positioned in any orientation since they are spill-proof, adding to their versatility.



Environmental and Safety Considerations

While VRLA batteries are safer than traditional flooded lead-acid batteries due to their sealed nature, they still require proper disposal at the end of their life cycle due to the presence of lead. However, many manufacturers, including Core Power, participate in recycling programs to mitigate environmental impact.



In conclusion, the Core Power VRLA UPS Battery represents a dependable, maintenance-free solution for power backup, ensuring that operations in critical environments can continue uninterrupted, safeguarding data, health services, and industrial processes against the unpredictability of power supply.

Cell Per Unit : 6

Voltage Per Unit : 12

Capacity : 1.3Ah@10hr-rate

Weight : Approx 0.52kg

Max. Discharge Current :19.5A (5 sec)

Internaal Resistance : Approx 43mΩ

Cell Per Unit : 6

Voltage Per Unit : 12

Capacity : 5Ah@20hr-rate

Weight : Approx 1.5kg

Max. Discharge Current :75A (5 sec)

Internaal Resistance : Approx 35mΩ

Cell Per Unit : 6

Voltage Per Unit : 12

Capacity : 7.5Ah@20hr-rate

Weight : Approx 2.0 kg

Max. Discharge Current :105A (5 sec)

Internaal Resistance : Approx 28mΩ

Cell Per Unit : 6

Voltage Per Unit : 12

Capacity : 9Ah@20hr-rate

Weight : Approx 2.5kg

Max. Discharge Current :135 (5 sec)

Internaal Resistance : Approx 21mΩ

Cell Per Unit : 6

Voltage Per Unit : 12

Capacity : 12Ah@10hr-rate

Weight : Approx 3.15kg

Max. Discharge Current :180A (5 sec)

Internaal Resistance : Approx 19mΩ

Cell Per Unit : 6

Voltage Per Unit : 12

Capacity : 18Ah@10hr-rate

Weight : Approx 5.2 kg

Max. Discharge Current :200A (5 sec)

Internaal Resistance : Approx 8.5mΩ

Cell Per Unit : 6

Voltage Per Unit : 12

Capacity : 10Ah@10hr-rate

Weight : Approx 6.5kg

Max. Discharge Current :280A (5 sec)

Internaal Resistance : Approx 9mΩ

Cell Per Unit : 6

Voltage Per Unit : 12

Capacity : 26Ah@10hr-rate

Weight : Approx 8kg

Max. Discharge Current :300A (5 sec)

Internaal Resistance : Approx 8mΩ

Cell Per Unit : 6

Voltage Per Unit : 12

Capacity : 33Ah@10hr-rate

Weight : Approx 10.5 kg

Max. Discharge Current :330A (5 sec)

Internaal Resistance : Approx 5.5mΩ

Cell Per Unit : 6

Voltage Per Unit : 12

Capacity : 45Ah@10hr-rate

Weight : Approx 12kg

Max. Discharge Current :400A (5 sec)

Internaal Resistance : Approx 7.8mΩ

Cell Per Unit : 6

Voltage Per Unit : 12

Capacity : 55Ah@10hr-rate

Weight : Approx 16kg

Max. Discharge Current :550A (5 sec)

Internaal Resistance : Approx 6.8mΩ

Cell Per Unit : 6

Voltage Per Unit : 12

Capacity : 100Ah@10hr-rate

Weight : Approx 18 kg

Max. Discharge Current :600A (5 sec)

Internaal Resistance : Approx 5.5mΩ
